NxM Multimode FBT Splitters, also known as TAPs and fused couplers, allow N fiber input(s) to be split into M outputs.
For example, when a fiber optic light beam is transmitted through the 1x4 70:10:10:10 OM3 multimode FBT Splitter, it will be divided into 4 beams, one of which is 70% of the original source, and each of the other 3 beams is 10%.
The FBT Splitters are suitable for LAN, CATV system, fiber optic instrument, fiber sensors, broadband network expansion and traffic monitoring system.
|
|
|
■ Available fiber type: OM1 62.5/125, OM2 50/125, OM3 50/125, OM4 50/125 ■ Various port configurations and split ratios available ■ Multiple operating wavelength, such as 850nm single window, 850nm&1310nm dual window, 1310nm&1550nm dual window ■ Available with 250µm bare fiber and 900µm, 2mm, 3mm loose tube fiber ■ Available unconnectorized or with any fiber optic connector: LC/APC, LC/UPC, SC/APC, SC/UPC, FC/APC, FC/UPC, etc. ■ Offer a variety of package, including steel tube, ABS box, metal module, LGX, rackmount |
|
■ High-density compact design saves space ■ Using high-quality optical fiber, connector and adapter to ensure the stability of signal transmission ■ Provide customized services to meet the requirements and application of different customers ■ Telcordia GR-1209-CORE and RoHS compliant |
|
|
